PACKAGED SYSTEM

The Packaged system is the most rapid and economic solution for the conditioning, treatment, purification, air renewal of shopping centres, restaurants, bars, outlet villages, showrooms, offices, production areas, railway stations, airports, conference halls, cinemas, theatres, discos.
The system is based on units specialized for conditioning places with different needs of air renewal: spaces that need a total air renewal, large, medium or low attendance spaces.The cooled or heated energy necessary for conditioning is produced locally only when needed and sent to the served areas by means of a suited air distribution and diffusion plant constituted by ducting and diffusion terminals.

Among the packaged systems stands out Multiplex Clima Solution, the system dedicated to multiplex cinemas, with over 1.000 cinemas served.

Discover the Multipex System

Why choose Packaged solution

DECENTRALIZATION AND REALIBILITY

Each served area is independent of the other to exactly meet the need for comfort. Over 25 years of experience and complete industrialization of units guarantee high reliability.

REDUCTION OF MANAGEMENT COSTS

The management costs are reduced thanks to: high efficiency of the refrigeration circuit optimized for the operation at part load, free-cooling, energy recovery in series with air exhaust, airflow control.

ENLARGEABLE OVER TIME

The system allows successive expansions of the system, or change of destination and arrangement of the air-conditioned surfaces, as the units are completely autonomous one from each other.

PRODUCT FOR EACH APPLICATION

The packaged system meets the comfort needs of medium and large surfaces thanks to a range of units specialised for application-medium, high, crowding and full-fresh air - with capacities from 13 to 376 kW and airflows from 600 to 16.700 l/s.

The system's elements

Units for applications in medium attendance areas SMARTPACK

Units for applications in medium attendance areas SMARTPACK

The SMARTPACK CKN-XHE2i packaged units from 20 to 45 kW, purify and renew the air in small and medium size areas.


Rooftop for applications in medium attendance areas CLIVETPACK2

Units for applications in medium attendance areas CLIVETPACK2

The CLIVETPack2 CSRT-XHE2 (air-cooled cooling only), CSRN-XHE2 (air-cooled heat pump) and CRH-XHE2 (water-cooled heat pump) packaged units with capacities from 50 to 376 kW and airflows from 2500 to 16700 l/s treat, purify and renew the air in medium and large attendance areas.


Rooftop for applications in large attendance areas CLIVETPACK2

Units for applications in large attendance areas CLIVETPACK2

The CLIVETPack2 CSNX-XHE2 packaged units with capacities from 47 to 174 kW and airflows from 1250 to 5000 l/s treat, purify and renew the air in large attendance areas such as cinemas, auditoriums, theatres.



Units for applications at full-fresh air

The CLIVETPack2 CSRN-XHE2 - FFA packaged units with capacities from 33 to 90 kW and airflows from 944 to 2200 l/s treat, purify and renew the air in areas needing full-fresh air conditioning such as chemical laboratories, commercial kitchens, morgues.


Best practices

 CANTALOU CHOCOLATE WHAREHOUSE

CANTALOU CHOCOLATE WHAREHOUSE

Pallejá, Barcelona - Spain
Wharehouse
System PACKAGED
Year 2008

 ALTROMONDO STUDIOS

ALTROMONDO STUDIOS

Rimini - Italy
Disco, 3000 people
Packaged
Year 2016

 AZIENDA AGRARIA CIUCCIOVÈ

AZIENDA AGRARIA CIUCCIOVÈ

Montecassiano,  Macerata - Italy
Greenhouse, 60 nurseries
Packaged– Geotermal
Year 2015

 LIBRARY AND CIVIC CENTER

LIBRARY AND CIVIC CENTER

Arese, - Italy
Library and civic center, A Class
Hydronic + Packaged System
Year 2016

 CASA VERDE NOCE

CASA VERDE NOCE

Milan – Italy
Residential Complex
Hydronic System
Year 2020
 CENTRO INGROSSO CINA

CENTRO INGROSSO CINA

Agrate Brianza, Milan – Italy
Packaged System
Year 2016


 CIBUS E' ITALIA – EXPO MILANO 2015

CIBUS E' ITALIA – EXPO MILANO 2015

Milan – Italy
Expo 2015 pavilion
Hydronic and Rooftop System and Primary Air
Año 2015
 EXPOCENTER

EXPOCENTER

Moscow - Russia
Packaged System
 FICO EATALY WORLD

FICO EATALY WORLD

Bologna - Italy
The largest food park in the world
Packaged System
Year 2017
 FIERE DI PARMA

FIERE DI PARMA

Parma - Italy
Exhibition Centre
Packaged System
Year 2006-2011

 IKEA Mallorca

IKEA Mallorca

Palma de Mallorca, Spain
Commercial Center
Packaged System
Year 2015

 MAC

MAC

La Coruña - Spain
Contemporary Art Museum
Packaged System
Year 2016
 McARTHURGLEN

McARTHURGLEN

Noventa di Piave, VE - Italy
Outlet Village, 55 shops
Split System
Year 2009

 MCARTHURGLEN DESIGNER OUTLET

MCARTHURGLEN DESIGNER OUTLET

Alessandria  - Italy
Outlet Village, 51.500 mq
Packaged + Split system
Year 2016

 PABELLÒN DEPORTIVO

PABELLÒN DEPORTIVO

Tona, Barcellona - Spain
Sport Club Association
Packaged GSHP System
Year 2009

 PALASPORT

PALASPORT

Massa Carrara - Italy
Hydronic + Packaged System
Year 2019
 Palazzetto di Massa

Palazzetto di Massa

Massa, Massa-Carrara – Italy
Sports Hall
Packaged + Hydronic System
Year 2019
 PARCO RAINBOW MAGICLAND

PARCO RAINBOW MAGICLAND

Valmontone, Rome – Italy
Packaged System
Year 2011


 PORSCHE HAUS

PORSCHE HAUS

Milan – Italia
Showroom and Sports Cars Service
Packaged System + Hydronic
Year 2011



 PROEIXAMPLE

PROEIXAMPLE

Barcelona  - Spain
Municipal building of equipment
Packaged and VRF System
Year 2010
